FA480 AC/DC Digital Clamp Meter – Precision Current and Voltage Tester

Model Number FA480
Dimensions 298*100*48mm
Weight 0.725kg
DC Voltage 6.6V/66V/660V/1000V

Overview

The FA Series Clamp Meter is a portable, professional-grade tool featuring a 3999-count auto-ranging display. Designed for versatile applications, it accurately measures DC/AC voltage, DC/AC current, resistance, capacitance, frequency, duty cycle, temperature, and also supports diode and continuity testing — all powered by battery operation.

Equipped with a large LCD screen and backlight function, it ensures clear data visibility even in low-light environments. The FA480 model includes a low battery indicator to remind users to replace the battery in time. For enhanced safety, it features an intelligent protection system that automatically responds to over-voltage or over-current conditions, safeguarding the meter from potential damage.

Type	FA280	FA370	FA480
DC Voltage	600mV/6.6V/66V/600V	0.4V/4V/40V/400V/1000V	6.6V/66V/660V/1000V
Accuracy	(±0.8%+3)	(±0.7%+1)	(±0.8%+3)
AC Voltage	600mV/6.6V/66V/600V	4V/40V/400V/750V	6.6V/66V/660V/750V
Accuracy	(±1.2%+3)	(±0.8%+1)	(±1.2%+5)
DC Current	66A/600A	400A/1000A	660A/2000A
Accuracy	(±3.0%+10)	(±3.0%+3)	(±2.5%+5)
AC Current	66A/600A	400A/1000A	660A/2000A
Accuracy	(±3.0%+10)	(±3.0%+3)	(±2.5%+5)
Frequency	10kHz	40Hz/400Hz/4kHz/40kHz/100kHz	66Hz/660Hz/6.6kHz/66kHz/660kHz/6.6MHz/20MHz
Accuracy	(±1.5%+5)	(±2%+1)	(±0.1%+3)
Resistance	660Ω/6.6kΩ/66kΩ/660kΩ/6.6mΩ/66mΩ	400Ω/4kΩ/40kΩ/400kΩ/4mΩ/40mΩ	660Ω/6.6kΩ/66kΩ/6.6mΩ/66mΩ
Jaw Capability	26mm	42mm	63mm
Power	1.5V(AAA)×3	6F22, 9V	6F22, 9V
Dimension	280×78×35mm	250×99×43mm	298×100×48mm
